Netafim Apollo Disc-Kleen Filter Battery, Twin

Original price was: $302.00.Current price is: $98.99.

Container Size

Clear

SKU: NF-T-KFB-AC Categories: Drip Irrigation, Drip Irrigation Filters

100% High-Quality Guarantee
Safe Shopping Guaranteed
100% environmentally friendly material
Sustainable materials, for a better tomorrow.

Netafim Product Documents

APOLLO DISC-KLEEN AUTOMATIC FILTER

A HIGH PERFORMANCE, RELIABLE, COST-EFFECTIVE FILTRATION SOLUTION

This filter offers maximum performance for systems requiring filtration for large volumes of water. A longer filter element with larger discs produces a larger filtration area and only 30 psi is required for backflushing. Made from high-density synthetic materials, the Apollo filter is corrosion-proof not just corrosion-resistant. Available in 24VAC or 12VDC and multiple filter configurations for maximum system flexibility. Requires separate purchase of backflush controller.

HOW AUTOMATIC DISC FILTER TECHNOLOGY WORKS

Disc Filters fall into the category of ‘depth filtration’ filters because they add an additional dimension to the cleaning process. A fislter element (spine) contains a stack of compressed discs with an overlapping series of grooves that force the debris to move through numerous trap points. This process increases the likelihood of capturing debris. Because of the increase in filtration surface area, the frequency of cleaning drops and cleaning is easier.

FILTRATION PROCESS

During the filtration process, unfi ltered water passes through the stack of tightly compressed discs, debris is trapped by the interlocking grooves of the disc rings, and only filtered water is released to the irrigation system.

BACKFLUSH PROCESS

As debris in the filter increases, the backfl ush process is initiated. The discs separate and jets of clean water spray and spin the discs removing the trapped debris which is then flushed out.

SAVE MONEY BY REDUCING FILTER SIZE

The Apollo features a longer filter element (spine) with larger discs (rings) producing a larger filtration area which accommodates a higher flow rate so the total number of filter units is reduced – lowering the filter cost.

SAVE MONEY BY REDUCING PUMP SIZE

Only 30 psi is required for backflushing reducing the need to oversize the pump for adequate flushing and it also reduces the need for a Pressure Sustaining Valve.

SAVE TIME & MONEY WHEN MOVING

The Apollo is light-weight with a small footprint making it portable and easy to move which is ideal for crop rotations and rental units in row crop applications.

SAVE MONEY ON MAINTENANCE

Made from high density synthetic materials, it’s corrosion-proof not just corrosion resistant. Chemical injection upstream will not damage any filter components.

Applications

For surface water containing algae and other organic materials such as reservoirs, canals, rivers and wastewater applications
For well water containing light sand (<3 ppm) and other contaminants

Specifications

4″ drain manifold inlet – outlet connections: Grooved
Maximum operating pressure:
- Standard model: 90 psi
- High pressure model: 140 psi
Minimum pressure required for backflush: 30 psi downstream of filters during backflush
Maximum operating temperature: 158° F
Minimum allowable pH: 5
Minimum operating pressure for filtration: 20 psi
Backflush flow rate @ 35 psi: 190 GPM
Includes backflush controller

Container Size	3 Filters – 120 Mesh AC Solenoid (26ASK4PB3120AC), 5 Filters – 120 Mesh DC Solenoid (26ASK4PB5120DC), 4 Filters – 120 Mesh AC Solenoid (26ASK4PB4120AC), 3 Filters – 120 Mesh DC Solenoid (26ASK4PB3120DC), 4 Filters – 120 Mesh DC Solenoid (26ASK4PB4120DC), 5 Filters – 120 Mesh AC Solenoid (26ASK4PB5120AC)
